Today, in the next eposide on my Personal AS series, I have added a third POP / fourth router, and that means I need to configure the POP all over again. That’s a lot of work, so I automated it with Ansible! Also follow along to see my first use of Netbox for automation

Contents⌗

Video⌗

Ansible Inventory⌗

Here’s the final version of my Ansible inventory/hosts.yml file. Long term, ideally I can move all of these attributes to custom attributes in Netbox, or even pulling the whole inventory from Netbox, instead of maintaining this file separately.

routers:
  hosts:
    waw-pe1.apalrd.fi:
      router_id: 1
      host: waw-pe1
      nat64: true
      pop: waw
      backup: true
      peers:
        - lax-pe1.apalrd.fi
        - sjy-p1.apalrd.fi
        - grr-e1.apalrd.fi
    lax-pe1.apalrd.fi:
      router_id: 2
      host: lax-pe1
      nat64: true
      pop: lax
      backup: true
      peers:
        - waw-pe1.apalrd.fi
        - sjy-p1.apalrd.fi
        - grr-e1.apalrd.fi
    sjy-p1.apalrd.fi:
      router_id: 3
      host: sjy-p1
      peers:
        - waw-pe1.apalrd.fi
        - lax-pe1.apalrd.fi
        - grr-e1.apalrd.fi
    grr-e1.apalrd.fi:
      router_id: 4
      host: grr-e1
      nat64: true
      pop: grr
      backup: true
      peers:
        - sjy-p1.apalrd.fi
        - waw-pe1.apalrd.fi
        - lax-pe1.apalrd.fi

Ansible Software Setup⌗

This is the script that installs all of the software (and running it again will update it!), enables backups, etc.

- hosts: "*"
  tasks:
#Global package update
    - name: apt upgrade
      apt:
        update_cache: yes
        upgrade: yes
#Packages required to install package repos
    - name: Pre required packages
      ansible.builtin.apt:
        pkg:
          - apt-transport-https
          - ca-certificates
          - gpg
#Backup to PBS
    - name: Proxmox apt key
      ansible.builtin.get_url:
        url: https://enterprise.proxmox.com/debian/proxmox-archive-keyring-trixie.gpg
        dest: /usr/share/keyrings/proxmox-archive-keyring.gpg
      when: backup is defined and backup
    - name: Proxmox client repository
      ansible.builtin.apt_repository:
        repo: "deb [arch=amd64 signed-by=/usr/share/keyrings/proxmox-archive-keyring.gpg] http://download.proxmox.com/debian/pbs-client {{ ansible_distribution_release }} main"
        state: present
      when: backup is defined and backup
    - name: Proxmox Backup Client install from packages
      ansible.builtin.apt:
        update_cache: yes
        name: proxmox-backup-client
      when: backup is defined and backup
    - name: Copy Proxmox Backup Service
      ansible.builtin.template:
        src: proxmox-backup.service
        dest: /etc/systemd/system/
        owner: root
        group: root
        mode: '0644'
      when: backup is defined and backup
    - name: Copy Proxmox Backup Timer
      ansible.builtin.template:
        src: proxmox-backup.timer
        dest: /etc/systemd/system/
        owner: root
        group: root
        mode: '0644'
      when: backup is defined and backup
    - name: Enable backup timer
      ansible.builtin.systemd_service:
        name: proxmox-backup.timer
        enabled: "{{ backup | default(false)}}"
        daemon-reload: True
#Configuration for bird3
    - name: bird3
      block:
      #Package install steps
        - name: bird3 apt key
          ansible.builtin.get_url:
            url: https://pkg.labs.nic.cz/gpg
            dest: /usr/share/keyrings/cznic-labs-pkg.gpg
        - name: bird3 repo
          ansible.builtin.apt_repository:
            repo: "deb [signed-by=/usr/share/keyrings/cznic-labs-pkg.gpg] https://pkg.labs.nic.cz/bird3 {{ ansible_distribution_release }} main"
            state: present
        - name: Bird3 install from packages
          ansible.builtin.apt:
            update_cache: yes
            name: bird3
#Tayga
    - name: Tayga
      when: nat64 is defined and nat64
      block:
        - name: tayga required packages
          ansible.builtin.apt:
            pkg:
              - build-essential
              - git
        - name: Git checkout
          ansible.builtin.git:
            repo: 'https://github.com/apalrd/tayga'
            dest: /root/tayga
            force: true
        - name: Compile
          ansible.builtin.shell:
            chdir: /root/tayga
            cmd: make && make install WITH_SYSTEMD=1 LIVE=1
        - name: Disable default nat64 instance
          ansible.builtin.systemd_service:
            name: tayga@default
            enabled: False
            state: stopped
        - name: Tayga local service
          ansible.builtin.systemd_service:
            name: tayga@local
            enabled: True
            state: started
        - name: Tayga wkpf service
          ansible.builtin.systemd_service:
            name: tayga@wkpf
            enabled: True
            state: started

Here’s my Proxmox Backup systemd service/timer, in case you want to use those too:

#/etc/systemd/system/proxmox-backup.service
[Unit]
Description=Run Backup to Proxmox Backup Server
After=network-online.target

[Service]
Environment=PBS_PASSWORD=your-api-key-nere
Environment=PBS_REPOSITORY=user@pbs!apikey@pbs.apalrd.fi:repo
Type=oneshot
ExecStart=proxmox-backup-client backup root.pxar:/

[Install]
WantedBy=default.target

#/etc/systemd/system/proxmox-backup.timer
[Unit]
Description=Backup System Daily
RefuseManualStart=no
RefuseManualStop=no

[Timer]
#Run 540 seconds after boot for the first time
OnBootSec=540
#Run at midnight UTC
OnCalendar=*-*-* 00:00:00
Unit=proxmox-backup.service

[Install]

Ansible Network Conf⌗

Here’s the two Ansible playbooks to configure systemd networkd:

#pop_conf_net.yml
- hosts: "*"
  collections:
    - netbox.netbox
    - ansible.utils
  vars:
    netbox_url: "https://docs.peach.apalrd.fi"
    netbox_token: 0DjI3ZTMQdQPEbti07i6KYnan8jOi0f2K9XS0Qm2
  tasks:
#Query peer primary addresses
    - name: Build peer_hosts list from inventory
      set_fact:
        peer_hosts: "{{ peer_hosts | default([]) + [hostvars[item].host] }}"
      loop: "{{ peers }}"
      when: hostvars[item].host is defined

    - name: Query potential peers from Netbox VM list
      set_fact:
        all_vms: >-
          {{
            lookup(
              'netbox.netbox.nb_lookup',
              'virtual-machines',
              api_endpoint=netbox_url,
              token=netbox_token,
              validate_certs=False
            )
          }}

    - name: Build IPv6 map for requested VMs
      set_fact:
        peer_ipv6_map: >-
          {{
            peer_ipv6_map | default({}) |
            combine({
              item.value.name:
                item.value.primary_ip6.address
                | ansible.utils.ipaddr('address')
            })
          }}
      loop: "{{ all_vms }}"
      no_log: true
      when:
        - item.value.name in peer_hosts
        - item.value.primary_ip6 is defined

    - name: Fail if any peer is missing
      fail:
        msg: "No primary IPv6 found in NetBox for: {{ peer_hosts | difference(peer_ipv6_map.keys() | list) }}"
      when: peer_hosts | difference(peer_ipv6_map.keys() | list) | length > 0

    - name: Show peer IPv6 addresses
      debug:
        msg: "Primary IPv6 for {{ item }} is {{ peer_ipv6_map[item] }}"
      loop: "{{peer_hosts}}"

    - name: Get my own IPv6 address
      set_fact:
        my_ip: >-
          {{
            (all_vms | selectattr('value.name','equalto',host) | list)[0].value.primary_ip6.address
            | ansible.utils.ipaddr('address')
          }}

    - name: Show my own IPv6 address
      debug:
        msg: "My IP is {{my_ip}}"

#Configuration for Tunnel Interfaces
    - name: Tunnel Interfaces
      ansible.builtin.include_tasks:
        file: pop_conf_net_tunnel.yml
      loop: '{{ peers }}'
      loop_control:
        loop_var: peer
#Configuration for Loopback Interface
    - name: Loopback Addresses
      notify: Reload Networkd
      ansible.builtin.template:
          src: loopback.network
          dest: /etc/systemd/network/loopback.network
          owner: root
          group: root
          mode: '0644'
#Restart handlers
  handlers:
    - name: Reload Networkd
      ansible.builtin.shell:
        cmd: networkctl reload

And a sub-playbook to setup a singular tunnel:

#pop_conf_net_tunnel.yml
#Ansible script to manage one tunnel interface
- name: Tunnel to {{peer}}
  block:
    - name: Interface Template Netdev to {{peer}}
      notify: Reload Networkd
      ansible.builtin.template:
          src: tunnel.netdev
          dest: /etc/systemd/network/tun_{{hostvars[peer]['host']|replace("-", "_")}}.netdev
          owner: root
          group: root
          mode: '0644'
    - name: Interface Template Network to {{peer}}
      notify: Reload Networkd
      ansible.builtin.template:
          src: tunnel.network
          dest: /etc/systemd/network/tun_{{hostvars[peer]['host']|replace("-", "_")}}.network
          owner: root
          group: root
          mode: '0644'

They also rely on two template files, for netdev and network:

#tunnel.netdev
#Tunnel to {{peer}}
[NetDev]
Name=tun_{{hostvars[peer]['host']|replace("-", "_")}}
Kind=ip6tnl

[Tunnel]
Mode=ip6ip6
Local={{ my_ip }}
Remote={{ peer_ipv6_map[hostvars[peer]['host']] }}
TTL=64
Independent=True

#tunnel.network
#Tunnel to {{peer}}
[Match]
Name=tun_{{hostvars[peer]['host']|replace("-", "_")}}

[Network]
Address=fe80::{{router_id}}/64
ConfigureWithoutCarrier=yes

Ansible Routing Conf⌗

Here’s what my templated BIRD conf looks like:

- hosts: "*"
  collections:
    - netbox.netbox
    - ansible.utils
  vars:
    netbox_url: "https://docs.peach.apalrd.fi"
    netbox_token: 0DjI3ZTMQdQPEbti07i6KYnan8jOi0f2K9XS0Qm2
    netbox_validate_certs: False
  tasks:
#Build prefix lists
    - name: Query NetBox for bgp-adv-dfz-ac prefixes
      set_fact:
        dfz_ac_prefixes: >-
          {{
            query(
              'netbox.netbox.nb_lookup',
              'prefixes',
              api_endpoint=netbox_url,
              token=netbox_token,
              validate_certs=netbox_validate_certs | default(true),
              api_filter="tag=bgp-adv-dfz-ac"
            )
            | map(attribute='value')
            | map(attribute='prefix')
            | list
          }}
      when: pop is defined
    - name: Show prefixes for AC
      debug:
        msg: "Prefix for AC: {{ item }}"
      loop: "{{dfz_ac_prefixes}}"
      when: pop is defined
    - name: Query NetBox for pop specific prefixes
      set_fact:
        dfz_pop_prefixes: >-
          {{
            query(
              'netbox.netbox.nb_lookup',
              'prefixes',
              api_endpoint=netbox_url,
              token=netbox_token,
              validate_certs=netbox_validate_certs | default(true),
              api_filter="tag=bgp-adv-dfz-" ~ pop
            )
            | map(attribute='value')
            | map(attribute='prefix')
            | list
          }}
      when: pop is defined
    - name: Show prefixes for POP
      debug:
        msg: "Prefix for POP: {{ item }}}"
      loop: "{{dfz_pop_prefixes}}"
      when: pop is defined
#Configuration for bird3
    - name: Bird3 copy common defs
      notify: Reload Bird
      ansible.builtin.template:
        src: bird-defs.conf
        dest: /etc/bird/defs.conf
        owner: root
        group: root
        mode: '0644'
    - name: Bird3 template IGP peers
      notify: Reload Bird
      ansible.builtin.template:
        src: bird-igp.conf
        dest: /etc/bird/igp.conf
        owner: root
        group: root
        mode: '0644'
    - name: Bird3 template iBGP peers
      notify: Reload Bird
      ansible.builtin.template:
        src: bird-ibgp.conf
        dest: /etc/bird/ibgp.conf
        owner: root
        group: root
        mode: '0644'
    - name: Bird3 template exports
      notify: Reload Bird
      ansible.builtin.template:
        src: bird-exports.conf
        dest: /etc/bird/exports.conf
        owner: root
        group: root
        mode: '0644'
    - name: Bird3 node-specific file
      notify: Reload Bird
      ansible.builtin.copy:
        src: bird-{{host}}.conf
        dest: /etc/bird/bird.conf
        owner: root
        group: root
        mode: '0644'
#Configuration for Tayga
    - name: Tayga configuration for local nat
      notify: Restart Tayga Local
      when: nat64 is defined and nat64
      ansible.builtin.template:
        src: tayga_local.conf
        dest: /etc/tayga/local.conf
        owner: root
        group: root
        mode: '0644'
    - name: Tayga configuration for wkpf nat
      notify: Restart Tayga Wkpf
      when: nat64 is defined and nat64
      ansible.builtin.template:
        src: tayga_wkpf.conf
        dest: /etc/tayga/wkpf.conf
        owner: root
        group: root
        mode: '0644'
#Restart handlers
  handlers:
    - name: Reload Bird
      ansible.builtin.shell:
        cmd: birdc configure
    - name: Restart Tayga Local
      ansible.builtin.systemd_service:
        name: tayga@local
        state: restarted
    - name: Restart Tayga Wkpf
      ansible.builtin.systemd_service:
        name: tayga@wkpf
        state: restarted

It depends on a bunch of other files, which are templated (with Jinja):

#bird-defs.conf
# My AS
define MY_AS = 201726;

# IP addresses of routers
define IP_MINE = 2a0f:b240:1000::{{router_id}};
define IP_WAW_PE1 = 2a0f:b240:1000::1;
define IP_LAX_PE1 = 2a0f:b240:1000::2;
define IP_SJW_P1 = 2a0f:b240:1000::3;
define IP_GRR_E1 = 2a0f:b240:1000::4;

# Where the route entered
define BGP_ENTER_MINE = (ro, MY_AS, {{router_id}});
define BGP_ENTER_WAW = (ro, MY_AS,1);
define BGP_ENTER_LAX = (ro, MY_AS,2);
define BGP_ENTER_SJW = (ro, MY_AS,3);
define BGP_ENTER_GRR = (ro, MY_AS,4);

# Redistribute this route to DFZ
define BGP_TO_DFZ_MINE = (ro, MY_AS, {{ 420+router_id }});
define BGP_TO_DFZ_ALL = (ro, MY_AS,420);
define BGP_TO_DFZ_WAW = (ro, MY_AS,421);
define BGP_TO_DFZ_LAX = (ro, MY_AS,422);
define BGP_TO_DFZ_GRR = (ro, MY_AS,424);

# IGP-related
define BGP_TO_IGP = (ro, MY_AS,667);
define BGP_TO_HELL = (ro, MY_AS,666);

# This route is via nat64
define BGP_NAT64 = (ro, MY_AS,64);

#bird-exports.conf
# This file is generated by a template!
# Routes for export
protocol static adv_v6 {
    ipv6;
    # My own loopback address goes into the IGP
    route 2a0f:b240:1000::{{router_id}}/128 via "lo" {
        bgp_ext_community.add(BGP_TO_IGP);
    };
{% if pop is defined %}
{% for prefix in dfz_ac_prefixes %}
    # Routes which will be advertised as anycast
    route {{prefix}} blackhole {
        bgp_ext_community.add(BGP_TO_DFZ_ALL);
        bgp_ext_community.add(BGP_ENTER_MINE);
    };
{% endfor %}
    # Routes which will be advertised from this pop
{% for prefix in dfz_pop_prefixes %}
    route {{prefix}} blackhole {
        bgp_ext_community.add(BGP_TO_DFZ_MINE);
        bgp_ext_community.add(BGP_ENTER_MINE);
    };
{% endfor %}
{% endif %}
{% if nat64 is defined and nat64 %}
    # Routes for nat64
    route 64:ff9b:1:{{router_id}}::/64 via "nat64" {
        bgp_ext_community.add(BGP_NAT64);
        bgp_ext_community.add(BGP_ENTER_MINE);
    };
    route 64:ff9b::/64 via "nat64wkpf" {
        bgp_ext_community.add(BGP_NAT64);
        bgp_ext_community.add(BGP_ENTER_MINE);
    };
{% endif %}
};

#bird-igp.conf
# This file is generated by a template!
# It configures the IGP (OSPFv3) functionality for a given node
protocol ospf v3 ospf6 {
    ipv6 {
        import all;
        export filter {
            # only send routes which we specifically want going into the IGP
            # and which are static routes from this router, not via iBGP
            if (proto = "adv_v6" && bgp_ext_community ~ [ BGP_TO_IGP ]) then accept;
            reject;
        };
    };

    # All OSPF is in area zero
    area 0 {
{% for peer in peers %}
        # Interface for neighbor {{peer}}
        interface "tun_{{hostvars[peer]['host']|replace("-", "_")}}" {
            type ptmp;
            check link no;
            cost 10;
            hello 5;
            dead 20;
            neighbors {
                fe80::{{hostvars[peer]['router_id']}};
            };
        };
{% endfor %}
    };
};

#bird-ibgp.conf
# This file is generated by a template!
# It configures iBGP peerings for a given node (full mesh)


# BGP locally within AS
filter to_bgp_local {
    #For routes which we advertised
    if proto = "adv_v6" then {
        bgp_origin = ORIGIN_INCOMPLETE;
        bgp_local_pref = 100;
        bgp_next_hop = IP_MINE;
        accept;
    }
    #For routes which came from the DFZ, set our own nexthop
    if proto = "dfz_v6" || proto = "dfz_v4" then {
        bgp_med = 100;
        bgp_next_hop = IP_MINE;
        accept;
    }
    #For routes which came from the anywhere else, redistribute as-is
    accept;
};


{% for peer in peers %}
protocol bgp bgp_local_{{hostvars[peer]['host']|replace("-", "_")}} {
    local as MY_AS;
    neighbor 2a0f:b240:1000::{{hostvars[peer]['router_id']}} as MY_AS;
    multihop;
    source address 2a0f:b240:1000::{{router_id}};
    ipv6 {
        import filter from_bgp_local;
        export filter to_bgp_local;
    };
};
{% endfor %}

I also use Tayga, and here is one of the Tayga configs:

#tun device
tun-device nat64
#prefix
prefix 64:ff9b:1:{{router_id}}::/96
ipv4-addr 192.0.0.8
#dynamic pool is apipa space
dynamic-pool 169.254.0.0/20
udp-cksum-mode fwd
log drop reject icmp self dyn
tun-up yes
tun-route 169.254.0.0/20
tun-route 64:ff9b:1:{{router_id}}::/64

How I Automated my Network with Ansible
